5. Specifications
5.1. Transceiver Specifications
GENERAL
Microphone Connector: 8-Pin
Headphone Jack: 1/4 ” Stereo, accepts mono or stereo plug.
External CW Key Jack: 1/8 “ Stereo
External Speaker Jack: 1/8” Mono, accepts mono or stereo plug.
Aux DC Output Connector: RCA x2
Frequency Range TX: Ham Bands Only (160-6M)
ACC Din Connector: 8 PIN DIN Connector – Line In, Line Out, Aux PTT, Ext Key,
Clock/Data/Enable, Ground
DC Power Connector: Power Pole
Fuse: Automotive Blade Style Fuse, 25 Amp 32V
Frequency Range RX: 500 kHz – 30 MHz and 50 – 54MHz. Specifications apply within Amateur
Radio bands only.
Tuning Step Size: 1, 10, 100, 1000, 10000
Frequency Stability: Maximum +/- 0.5 PPM over operating temperature
Antenna Impedance: 50 ohms nominal.
Antenna Connectors: 1 x SO-239 transceive
Modes: USB, LSB, CW, AM (optional), FM (optional)
Memories: 100
Frequency Accuracy: ±5Hz @25°C, 1 Hz tuning resolution
Supply Voltage Range: 13.8V +/-15%
Operating Temp. Range: 0-50 degrees Celsius
Dimensions (HxWxD): 2.9” x 8.5” x 10.25” (excluding knobs and connectors)
Weight: 7.25 lbs with all options
Construction: Molded plastic front panel, aluminum chassis and texture painted steel
covers
PC Control Port: USB (using CCS USB to UART Driver)
Display: Custom FSTN monochrome LCD
Display Backlight: 256 colors X 16 intensity levels
All measurements are typical. Specifications are subject to change.
