599 / Eagle Users manual Release 1.009 CE – April 15, 2015
Part #74447
Printed in USA 28
RECEIVER
SSB Sensitivity: Better than 0.7uV, 2.4khz, 10dB SINAD, preamp off
AM Sensitivity: Better than 4uV, 30% Mod, 6kHz BW, 10dB SINAD, preamp off
FM Sensitivity: Better than 2.2uV, 5kHz Dev, 16kHz BW, 10dB SINAD, preamp off
Selectivity IF1: 2.4khz standard, 9.0015 MHz, 2 options
Selectivity IF2: 30 KHz Lowpass filter
Selectivity, DSP IF: 127 built-in DSP filters from 100-15000 Hz BW.
Third Order Intercept Point (IP3): Typical 20dBm@20kHz tone separation/2.4 kHz roofing filter,
17dBm@2kHz separation/600Hz roofing filter, S5 method, preamp off
IMD3 Dynamic Range: Typical 97dB/20kHz, 95dB/2kHz, 500Hz BW, calculated 2/3(IP3-Noise
Floor), preamp off
Blocking Dynamic Range: 138dB/20kHz, 127dB/2kHz, 500 Hz BW, RF gain @ 12 o'clock, preamp off
LO Phase Noise: Typical -132dBc/Hz @ 20kHz, -121dBc/Hz @ 2kHz
Noise Floor: Typical -132dBm/500Hz BW/preamp on, -126dBm preamp off
IF Frequencies: 1
st
:9.0015 MHz, 2
nd
:22.5 kHz, 3
rd
:0Hz (DSP)
IF Rejection: Better than 70dB
1
st
IF Image Rejection: Better than 90dB/HF bands, 70dB/6M
2
nd
IF Image Rejection: Better than 73dB
Other Spurious Response: Rejection: >80dB
Birdies: Typically less than -100dBm equivalent (no more than 5 birdies
greater than -100dBm equivalent)
Pass Band Tuning: +/- 2.1kHz, 5Hz steps. Small dead zone for centering
Attenuator: 10 db
PreAmp: Nominal 12 db
Audio Output: 2W into 4 ohms, <3% THD
RIT range: +/- 8.2 kHz
RIT Step size: 10Hz
S-Meter Reference: S9 = 50 uV RMS
TX>RX Recovery Time: < 20 ms
RX Headphone Output: Designed for 16-32 ohms impedance headphones. Usable at 8 ohms
AUX Audio Output: 500 mv
Auto Notch: IF DSP, multi-tone
RX Noise Reduction: IF DSP, adjustable
Noise Blanker: Optional daughter board, 2 levels of blanking
RX Current Drain: 1.25 Amps
General Coverage Receive: degraded specs outside ham bands
All measurements are typical. Results will vary based on different Test Environment, Tools, and
Test Methods. Specifications are subject to change.
