599 / Eagle Users manual Release 1.009 CE – April 15, 2015
Part #74447
Printed in USA 29
TRANSMITTER
RF Power Output: Adjustable, 5-100 W, +/- 1 dB
CW & SSB Duty Cycle: continuous service @ 100W
AM,FM,AFSK,PSK Duty Cycle: continuous service @100W, 50% duty cycle (Tx/Rx)
CW/SSB TX Bandwidth: 2.4kHz Filter
AM TX Bandwidth: 6kHz Optional Filter
FM TX Bandwidth: 15kHz Optional Filter
Microphone Input Impedance: >10 k-ohms at 1 kHz
Microphone Sensitivity: 1 mV RMS for full power output, internal gain adjustment, 9v dc power for
electret elements
FM Deviation: +/- 5 kHz peak nominal
AUX Level Input: variable, 200mV nominal
SSB Carrier Supression: > 70 dB
Unwanted Sideband Suppression: > 60 dB at 1 kHz
Harmonic & Spurious Outputs: <-50dBc @100 W <30MHz; -60dB >30MHz; -43 dB <5 W
T/R Switching: PTT or VOX on SSB, AM, FM, QSK on CW
CW Keyer Type: Internal Curtis Mode B
CW Rise and Fall Times: 5ms
CW Offset: adjustable
CW Keyer Speed: 5-50 WPM, adjustable weighting
Current Drain: transmit 20 amps typical
Third Order Intermod: Better than 25dB below peak
SSB Generation: DSP Generated
# of DSP generated TX bandwidths: 3 built-in DSP filters – automatically selected based on mode – for
CW/SSB = 2.4Khz; for optional AM = 6Khz; for optional FM = 12KHz
Note: the optional 6KHz filter is required for AM transmit, and the optional
15KHz filter is required for FM transmit.
ANTENNA TUNER (599AT)
Type: Reversible L-network
Matching frequency range: 160 to 10 Meters, no Six Meters
Matching impedance range: 10:1 SWR typical
OPTIONS
4 Pole Roofing Filters: 300Hz, 600Hz, 1.8kHz, 6kHz, 15kHz
Noise Blanker: daughter board module
Auto Tuner: daughter board module
All measurements are typical. Specifications are subject to change.
