Device Management
- 107 -
Tip
Ensure that addresses obtained by the WAN port can access the Internet.
An intranet computer IP address must be manually configured to avoid service interruption due to
automatic change of IP address.
System firewall, some pieces of antivirus software, and security software may prevent other computers from
accessing the server on the computer. You are recommended to disable them temporarily when using this
function.
Setup steps:
Step 1: Set port forwarding.
Click .
Set rule contents in the window that appears.
Intranet Host IP: Enter an IP address of the Internet server.
Intranet Port: Enter a port used by the server.
Extranet Port: Enter a router port open to the Extranet.
Protocol: Select service protocols. It is recommended to select all.
Mapped Line: Select a WAN port for Intranet service forwarding.
Click OK to finish settings.
After a port forwarding rule is successfully added, the page is shown in the figure below.
