Tenda O3 User Manual

150
If the rule is added successfully, it is displayed in the list below the Add button. See the following
figure:
Verification
Enter Protocol name://WAN port IP address:External port in the address bar of a web browser on
a computer over the internet to access the resources on the web server. In this example, enter
http://202.105.11.22:80.
If internet users still cannot visit the web server in LAN after the configuration, try the following
solutions:

Ensure that the WAN IP address of the device is a public IP address, and the internal port you
entered is correct.

Security software, antivirus software, and the built-in OS firewall of the computer may cause port
forwarding function failures. Disable them and try again.

Manually set an IP address and related parameters for the web server to avoid the service
disconnection caused by the dynamic IP address.

Tenda O3 Specifications

General

5 GHz	No
2.4 GHz	Yes
Number of users	15 user(s)
Transmitting power	29 dBmW
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Receiver sensitivity	MCS0: -88dBm MCS7: -72dBm
Maximum outdoor range	5000 m
Maximum data transfer rate	150 Mbit/s
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	1
Placement	Wall
Certification	FCC / CE / RoHS
Product color	White
LED indicators	LAN, Power, WAN
International Protection (IP) code	IP64
Antenna features	Integrated antenna
Antenna gain level (max)	12 dBi
Output current	1 A
Output voltage	12 V
Power consumption (max)	6 W
Security algorithms	WPA, WPA2, WPA2-PSK
Cables included	LAN (RJ-45)
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-20 - 55 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	94.86 mm
Width	270 mm
Height	67.5 mm
