Tenda O3 User Manual

133
8 Advanced
8.1 LAN rate
This module enables you to change LAN speed and duplex mode settings. If the transmission
distance between the ports of the CPE and peer device is too long, you can reduce the port speed
of the CPE and peer device to increase the driving distance.
When you change the settings, ensure that the LAN speed and duplex mode of the port of the
device is the same as that of peer device. By default, the LAN speed settings of the LAN port is
Auto Negotiation. OS3 is used for illustration.
To access the page, choose Advanced > LAN Rate.
Parameters description
Name
Description
Auto Negotiation
The speed and duplex mode of the port is determined by the negotiation between the
port and peer port.
100Mbps Full-Duplex
The port is under 100 Mbps, and can transmit and receive packets at the same time.
100Mbps Half-Duplex
The port is under 100 Mbps, and can only transmit or receive packets at the same
time.
10Mbps Full-Duplex
The port is under 10 Mbps, and can transmit and receive packets at the same time.
10Mbps Half-Duplex
The port is under 10 Mbps, and can only transmit or receive packets at the same time.

Tenda O3 Specifications

General

5 GHz	No
2.4 GHz	Yes
Number of users	15 user(s)
Transmitting power	29 dBmW
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Receiver sensitivity	MCS0: -88dBm MCS7: -72dBm
Maximum outdoor range	5000 m
Maximum data transfer rate	150 Mbit/s
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	1
Placement	Wall
Certification	FCC / CE / RoHS
Product color	White
LED indicators	LAN, Power, WAN
International Protection (IP) code	IP64
Antenna features	Integrated antenna
Antenna gain level (max)	12 dBi
Output current	1 A
Output voltage	12 V
Power consumption (max)	6 W
Security algorithms	WPA, WPA2, WPA2-PSK
Cables included	LAN (RJ-45)
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-20 - 55 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	94.86 mm
Width	270 mm
Height	67.5 mm
