Tenda O3 User Manual

152
----End
The added rule displays in the MAC filter list. The parameters on the picture below are used for
examples.
Parameters description
Name
Description
Mode
It specifies the mode of MAC filter rule.

Disable: Disable the MAC Filter function.

Allow: Allow the devices with the MAC addresses in the list to access the internet
via this device, and disallow the other devices to access the internet via this device.

Disallow: Disallow the devices with the MAC addresses in the list to access the
internet via this device, and allow the other devices to access the internet via this
device.
Remark
It specifies the additional information of the rule.
MAC Address
It specifies the MAC address of the device to which the rule applies.
Time
It specifies the period at which the rule takes effect.

Tenda O3 Specifications

General

5 GHz	No
2.4 GHz	Yes
Number of users	15 user(s)
Transmitting power	29 dBmW
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Receiver sensitivity	MCS0: -88dBm MCS7: -72dBm
Maximum outdoor range	5000 m
Maximum data transfer rate	150 Mbit/s
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	1
Placement	Wall
Certification	FCC / CE / RoHS
Product color	White
LED indicators	LAN, Power, WAN
International Protection (IP) code	IP64
Antenna features	Integrated antenna
Antenna gain level (max)	12 dBi
Output current	1 A
Output voltage	12 V
Power consumption (max)	6 W
Security algorithms	WPA, WPA2, WPA2-PSK
Cables included	LAN (RJ-45)
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-20 - 55 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	94.86 mm
Width	270 mm
Height	67.5 mm
