Tenda O3 User Manual

77
Name
Description
default, it is 192.168.2.1. You can access the web UI of this device using this IP
address.
Transparent Bridge
It displays the status of transparent bridge.
Connection Type
It specifies the internet connection type of this device in WISP or Router mode.

DHCP (Dynamic IP): The CPE obtains IP address from the upstream DHCP server
for internet access.

Static IP Address: The CPE uses a fixed IP address, subnet mask, default
gateway, and DNS server info for internet access.

PPPoE: The CPE uses a user name and password for internet access.
Connection Status
It specifies the connection status of WAN port of this device in WISP or Router
mode.
WAN IP Address
It specifies the IP address of WAN port of this device in WISP or Router mode.
Default Gateway
It specifies the default gateway address of this device in WISP or Router mode.
Primary DNS Server
It specifies the IP address of primary DNS server of this device in WISP or Router
mode.
Secondary DNS Server
It specifies the IP address of secondary DNS server of this device in WISP or
Router mode.

Tenda O3 Specifications

General

5 GHz	No
2.4 GHz	Yes
Number of users	15 user(s)
Transmitting power	29 dBmW
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Receiver sensitivity	MCS0: -88dBm MCS7: -72dBm
Maximum outdoor range	5000 m
Maximum data transfer rate	150 Mbit/s
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	1
Placement	Wall
Certification	FCC / CE / RoHS
Product color	White
LED indicators	LAN, Power, WAN
International Protection (IP) code	IP64
Antenna features	Integrated antenna
Antenna gain level (max)	12 dBi
Output current	1 A
Output voltage	12 V
Power consumption (max)	6 W
Security algorithms	WPA, WPA2, WPA2-PSK
Cables included	LAN (RJ-45)
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-20 - 55 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	94.86 mm
Width	270 mm
Height	67.5 mm
