Tenda O3 User Manual

84
5.3.4 ARP table
ARP (Address Resolution Protocol) is a network layer protocol used to convert an IP address into a
physical address. The ARP table displays the IP address and its corresponding MAC address the
device visits, and the interface the packets pass through.
Parameters description
Name
Description
IP Address
It specifies the IP address of the host in the APR table.
MAC Address
It specifies the MAC address corresponding to the IP address.
Interface
It specifies the interface used to communicate with the host, including LAN, WLAN
and bridge interfaces.

Tenda O3 Specifications

General

5 GHz	No
2.4 GHz	Yes
Number of users	15 user(s)
Transmitting power	29 dBmW
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Receiver sensitivity	MCS0: -88dBm MCS7: -72dBm
Maximum outdoor range	5000 m
Maximum data transfer rate	150 Mbit/s
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	1
Placement	Wall
Certification	FCC / CE / RoHS
Product color	White
LED indicators	LAN, Power, WAN
International Protection (IP) code	IP64
Antenna features	Integrated antenna
Antenna gain level (max)	12 dBi
Output current	1 A
Output voltage	12 V
Power consumption (max)	6 W
Security algorithms	WPA, WPA2, WPA2-PSK
Cables included	LAN (RJ-45)
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-20 - 55 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	94.86 mm
Width	270 mm
Height	67.5 mm
