Tenda PH10 User Manual

16
Parameters Description
Parameter
Description
Mode
11b/g/n: Only 802.11b, 802.11g, and 802.11n devices are allowed to connect the WiFi.
11b/g: Only 802.11b and 802.11g devices are allowed to connect the WiFi.
11b: Only 802.11b devices are allowed to connect the WiFi.
11g: Only 802.11g devices are allowed to connect the WiFi.
11ac: Only 802.11ac devices are allowed to connect the WiFi.
11a/n/ac: Only 802.11a, 802.11n, 802.11ac devices are allowed to connect the WiFi.
Wi-Fi
Channel
Do not change the channel unless you experience wireless connection failures or slow data
transmission. If this happens, try different channels to identify the optimal channel.
Wi-Fi
Bandwidth
Auto: This is the default channel bandwidth. Keep the default value.
20: Select this bandwidth if you experience wireless connection failures.
40: Select this bandwidth to maximize the wireless throughput at 2.4 GHz.
80: Select this bandwidth to maximize the wireless throughput at 5 GHz.

Tenda PH10 Specifications

General

Ethernet LAN	Yes
Certification	CE, FCC
Product color	White
LED indicators	Power, WLAN
Frequency range	2 - 86 MHz
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Antennas quantity	2
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Number of adapters included	1 pc(s)
Sustainability certificates	RoHS
WLAN data transfer rates supported	200, 433 Mbit/s
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Harmonized System (HS) code	85171800
