- 29 -
6 PoE Management
All Downlink Ports support PoE power supply and conform to IEEE 802.3af and IEEE
802.3at. The switch will automatically supply required PoE power to the powered device
which is connected with the PoE port.
Click PoE Management to enter the page below. You can check the PoE power status of
the current switch and enable/disable the PoE power function of the downlink port as well.
Tip
By default, the PoE power function of all switch downlink ports is enabled.
Parameter specification:
Check the box at the front of the corresponding port number to select
that port. Check the box at the top to select all of the ports.
To Next Page
