Technology Parameters
Features
Standards
IEEE802.3 10BASE-T Ethernet
IEEE802.3u 100BASE-TX/FX Fast
Ethernet
IEEE802.3 ab Gigabit Ethernet
IEEE802.x Flow Control supports for
Full Duplex
Protocol CSMA/CD
Topological Structure Star
Network Cables
10BASE-T:
Cat.3 UTP or above
100BASE-TX:
Cat.5 UTP /STP
1000Base-T: Cat.5 , Cat.5e or Cat.6
UTP/STP
Port Quantity 16/24 10/100/1000Mbps ports
Performance
Transmission Method Fast store-and-forward
MAC Address Table 8K
14880pps(10Mbps)per port
148800pps(100Mbps)per port
Packet Filtering/
Forwarding Rate
1488000pps(1000Mbps)per port
MAC Address Learning Self-learning, auto-aging.
Physical and Environmental
Power Internal universal power supply
AC INPUT AC100~240V, 50/60Hz
Power Consumption 15W/20W
Operating Temperature 0°C ~40°C
Storage Temperature -10°C ~70°C
Humidity 5%~95% RH (no condensing)
Dimensions
(L×W×H)
11.02in. ×7.09in. ×1.93in.
(280mm×180mm×44mm)
Weight
TEG1016D:1.70Kg/
TEG1024D:1.81Kg
