Tenda W150D User Manual

ADSL2/2+ Router
 MAC Address: Config device’s WAN MAC address. You can
either enter one manually or click the “Clone MAC” button to
copy your PC’s MAC.
 Clone MAC: Clicking this button changes device’s WAN MAC
address from default to the MAC address of the PC you are
currently on. Don’t use this button unless your PC’s MAC address
is the one bound by your ISP.
 Restore to Factory Default MAC: Restores device’s WAN MAC
to factory default.
Note: After you clicked “Restore to Factory Default
MAC”, you need to reboot the device to activate it.
4.3.4 DHCP
DHCP Server
DHCP server is enabled on the device by default. The Dynamic
Host Configuration Protocol (DHCP) is an automatic configuration
protocol used on IP networks. If you set all LAN PCs to “Obtain an IP
Address Automatically” and "Obtain DNS server address automatically",
they will automatically load proper TCP/IP settings provided by the
device DHCP server when turned on (including IP address, subnet
- 44 -

Tenda W150D Specifications

General

VPN support	PPPTP, L2TP, Ipsec
Ethernet LAN	Yes
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3u, IEEE 802.3x
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Wi-Fi band	No
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Channels quantity	13 channels
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
WLAN data transfer rate (max)	150 Mbit/s
Bandwidth	2.4 GHz
Interface	LAN, WAN, WLAN
USB ports quantity	0
Networking features	Ethernet, Fast Ethernet
Maximum data transfer rate	0.1 Gbit/s
Minimum system requirements	Internet Explorer 6.0 / Firefox 1.0
Supported data transfer rates	10/100Mbit/s
WLAN data transfer rates supported	11, 54, 150 Mbit/s
Supported network protocols	IPoE, PPPoE, PPPoA, IPoA, DHCP server
Security algorithms	WEP, WPA, WPA-PSK, WPA2, WPA2-PSK
Antennas quantity	1
Antenna gain level (max)	5 dBi
Web-based management	-
Ethernet LAN (RJ-45) ports	4
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	9 W
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Certification	FC, CE, RoHS
Cables included	LAN (RJ-45)
Product color	White
LED indicators	DSL, LAN, Link, Power, WAN, WLAN

Weight and Dimensions

Depth	171.95 mm
Width	118.97 mm
Height	31 mm
Weight	- g
