ADSL2/2+ Router
Enable: Check or uncheck to enable or disable the remote
web-based management feature.
Port: Enter a port number for remote web-based management.
IP Address: Enter the IP address of a PC on Internet authorized
to access and manage the device’s web-based utility remotely.
For example: If you want to allow only a PC at the IP address of
218.88.93.33 to access your router’s web-based utility from Internet via
port: 8080, then config same settings shown on the sreenshot on your
router. And what this IP user needs to do is to simply launch a browser
and enter http: //220.135.211.56:8080 (provided that the router’s WAN
IP address is 220.135.211.56).
Note:
If you enter 0.0.0.0 in the IP address box, then all PCs on Internet can
access your router’s Web-based utility to view or change your settings
remotely once you enable the remote Web-based management
featu
re.
- 82 -
