TECHNICAL SPECIFICATIONS
Accuracy is guaranteed for one year.
Ambient temperature: 23°C ± 5°C (73.4°F ± 9°F), relative humidity ≤75%.
Caution
• For accuracy, the temperature conditions should be controlled between 18°C and
28°C, while the uctuation range of the ambient temperature should be stabilised
within ±1°C.
• If the temperature is lower than 18°C or greater than 28°C, the additional
temperature coefcient error shall be 0.1 x (specied accuracy)/°C.
• If the change in ambient temperature is within ± 5°C, the accuracy is applied after
2 hours. Upon the completion of battery charging, the accuracy is also applied
after 2 hours.
MEASUREMENT OF DC VOLTAGE
Range Resolution
Accuracy ± (a% of reading + b counts)
DC
Frequency
response
45Hz-1kHz >1kHz-20kHz
600.00mV 10µV
± (0.025%
+ 5)
AC+DC ±(1.2% + 40) ± (6.0% + 40)6.0000V 100µV
60.000V 1mV
600.00V 10mV ± (0.03% + 5)
Undened
1000.0V 100mV ± (0.03% + 5)
Input Impedance
• Range ≥ 1GΩ, input impedance for other ranges is 10MΩ.
• AC+DC, the specications are dened for signal input > 10% of range.
MEASUREMENT OF AC VOLTAGE
Range Resolution
Accuracy ± (a% of reading + b counts)
45Hz-1kHz
>1kHz-
10kHz
>10kHz-
20kHz
>20kHz-
100kHz
600.00mV 10µV
± (0.4% +
40)
±(5.0% + 40) ±(5.5% + 40) ±(8.0% + 40)
6.0000V 100µV ±(1.2% + 40) ±(3.0% + 40) ±(8.0% + 40)
60.000V 1mV ±(1.2% + 40) ±(3.0% + 40) ±(6.0% + 40)
600.00V 10mV ±(3.0% + 40)
Undened
1000.0V 100mV
± (0.6% +
40)
±(3.5% + 40)
LoZ /
1000~V
0.1V ± (2% + 40)
V.F.C
600V/1000V
0.01V/0.1V ± (4% + 10) frequency response: 45 ~ 400Hz
