SPECIFICATION
Sampling
Sampling modes Real time Equivalent
Sampling rates
250MS/s (72-9355)
500MS/s (72-9360)
1GS/s (72-9365)
25GS/s
Sampling Sampling, peak detect, average
Average value
When all channels have made N samplings simultaneously,
N is selectable from 2, 4, 8, 16, 32, 64, 128 and 256
Input
Input coupling DC, AC, GND
Input impedance 1MΩ±2% in parallel with 21F±3pF
Probe attenuation 1X, 10X, 100X, 1000X
Maximum input voltage 400V(DC+AC peak)
Time delay between channels
(typical)
50ps
Horizontal
Waveform interpolation Linear
Record length 2 x 512K sampling point
Storage depth 7.5k
Scanning range (s/div)
At 1-2-5 increment.
2ns/div-50s/div (200MHz);
5ns/div-50s/div (100MHz, 60MHz);
Accuracy of sampling rate and
delay time
±50ppm (any time interval ≥1ms)
Time interval (rT)
measurement accuracy
(full bandwidth)
Single: ±(1 sampling time interval + 50ppm X reading + 0.6ns)
>16 average values: ±(1 sampling time interval + 50ppm x
reading + 0.4ns)
Vertical
Model 72-9365 72-9360 72-9355
Analogue bandwidth 200MHz 100MHz 60MHz
Single bandwidth 200MHz 100MHz 60MHz
Rise time 1.8ns, ≤2.3ns, ≤3.5ns, ≤4.3ns, ≤5.8ns, ≤8.7ns, ≤14ns
A/D converter 8-bit resolution
Deection gratitude factor
VOLTS/DIV Range
5mV/div ~ 50 V/div at input BNC
Displacement range ±10div
Selectable bandwidth limit
(Typical)
20MHz
• Unless otherwise specied, all technical specications apply to probes with 10X
attenuation setting, and the oscilloscope has been powered on for 30 minutes at
the specied ambient temperatures.
