Tenways AGO X - INSTALL THE FRONT MUDGUARD

No.3 Hex Key No.5 Hex Key No.4 Hex Key
Side View
Front View
01
Adjust the distance between
the mudguard and the tire, then
use the No.5 Hex Key to fix the
mudguard lug to the front fork.
The torque should be 8-10 Nm.
02
Use the No.4 Hex Key to fix the
mudguard
supports. The torque
should
be 3-4 Nm.
Tools needed: No.4 and
No.5 Hex Keys
INSTALL THE FRONT MUDGUARD
06.
013 Assemble your TENWAYS e-bike
