OLED display will invert every 10 minutes. You can set the display to invert every 30 minutes (lengthens
the display life), or it can dim or turn o after 10 seconds or 10 minutes.
• Reset All Settings - Reset all configurable options to their factory defaults.
• Device Info - Displays the model and serial number.
• Firmware versions - Displays the current firmware versions for all device components.
LAUNCHPAD
Launchpad allows you to configure, pair, and upgrade your Ranger device. Launchpad is available as
software for Mac and Windows at www.teradek.com/pages/downloads.
The following configuration options are available:
• Pairing - Pair or unpair your devices.
• Settings - Select the operating region (TX) and modify the RX/TX name.
� Select Region (TX) - Configure Ranger to comply with your region’s regulations governing use of
the 5GHz spectrum.
� Select TX/RX Name - Modify the transmitter or receiver’s name to make it easier to identify
among other Ranger systems that are present.
• Color Processing - Allows you to apply 3D LUTS to the receiver’s video output
• Upgrade - Update your devices with the latest firmware.
• Status - Displays detailed information about configuration and update statuses.
• About - Displays the software version and License Agreement.
13
