30
Terasic Inc.
D8M-GPIO User Manual
www.terasic.com
September 26, 2018
Terasic auto-focus IP through its own I2C master controller. Users must make sure
there is only one I2C master used a time.
KEY IP Descriptions
In this demonstration, the default camera settings are:
Terasic Camera IP implements RAW to RGB and avalon-ST streaming
package conversion.
Terasic AutoFocus IP implements Simplified AutoFocus function.
Scaler IP implements Scaling function. Combining with software
configuration, it can scale two 640x480 images to proper size to fit the
bandwidth limitations (100MHz x 16bit) of the SDRAM.
Frame Buffer IP can read and write image stream into the SDRAM
Mixer IP Camera will blend two image data into one picture (resolution is
800x600).
Clock Video Output block will output the image data (resolution is 800x600)
from the Mixer IP to the VGA monitor.
The default camera settings
In this demonstration, the default camera settings are:
Resolution: 600x480
Frame Rate: 50 fps
Pixel Data: RAW10
Bin Mode: 1, 2, 4 (achieved ZOOM-IN/ ZOOM-OUT function)
Camera1 default settings:
Resolution: 600x480
Frame Rate: 50 fps
Pixel Data: RAW10
Bin Mode: 1, 2, 4 (achieved ZOOM-IN/ ZOOM-OUT function)
Users can change the settings base on their requirements.
Synchronize Two D8M Data Streaming
There is a simple way to synchronize multiple D8M’s “Frame Start” signals. See Table
5-2 follow the “Hardware standby with PWDNB mode. After configuring all of the
D8M’s registers, just pulling all of the D8M’s “PWDNB” signal low for a while at the
same time. In this way, the register setting will not be clear and it will synchronize all
