Terex Genie GTH-4016 R User Manual

May 2015Second Edition - First Printing
Part No. 57.0009.0607 GTH 4016 R - GTH 4018 R - GTH-5021 R 101
Specifications
GTH-4018 R
Height, stowed 2.99 m
Length, stowed, at fork-holder plate
6.60 m
Width, standard tires 2.40 m
Wheelbase 3.00 m
Ground clearance, center 0.345 m
Weight 14,000 kg
Working fork height,
maximum
17.54 m
Horizontal reach maximum 15.53 m
Reach at maximum height 3.80 m
Lift capacity, maximum height
outriggers up
outriggers down
outriggers down & not aligned
1500 kg
2000 kg
2000 kg
Lift capacity, maximum reach
outriggers up
outriggers down
outriggers down & not aligned
0 kg
500 kg
500 kg
Maximum lift capacity 4,000 kg
Drive speed, maximum, 30 km/h
Chassis Levelling (if equipped) 7 +/- °
Turning radius, outside,
2 wheel steer
7.2 m
Turning radius, outside,
4 wheel steer
4.5 m
Fuel tank capacity 205 L
Maximum grade 40 %
Horn sound level,
manufacturer’s rating
110 dB
Backup alarm sound level,
manufacturer’s rating
95 dB
Mean assessed vibration level
transmitted to body
0.32 m/s
2
Sound pressure level at the operator
position (
in accordance with EN12053)
(only 3B Machine)
74 dB
Guaranteed sound power level LwA
(
in accordance with the Directive 2000/14/CE)
(only 3B Machine)
102 dB
Floor loading information
Tire load, maximum 7,245 kg
Occupied floor pressure 11.7 kPa
