102 GTH 4016 R - GTH 4018 R - GTH-5021 R Part No. 57.0009.0607
Specifications
GTH-5021 R
Height, stowed 2.99 m
Length, stowed, at fork-holder plate
7.17 m
Width, standard tires 2.42 m
Wheelbase 3.00 m
Ground clearance, center 0.36 m
Weight 17,180 kg
Working fork height,
maximum
20.86 m
Horizontal reach maximum 18.24 m
Reach at maximum height 3.91 m
Lift capacity, maximum height
outriggers up
outriggers down
outriggers down & not aligned
2,000 kg
3,000 kg
250 kg
Lift capacity, maximum reach
outriggers up
outriggers down
outriggers down & not aligned
0 kg
475 kg
0 kg
Maximum lift capacity 5,000 kg
Drive speed, maximum, 30 km/h
Chassis Levelling (if equipped) +/- 6°
Turning radius, outside,
2 wheel steer
7.35 m
Turning radius, outside,
4 wheel steer
4.22 m
Fuel tank capacity 205 L
Maximum grade 38 %
Horn sound level,
manufacturer’s rating
110 dB
Backup alarm sound level,
manufacturer’s rating
95 dB
Mean assessed vibration level
transmitted to body
0.32 m/s
2
Sound pressure level at the operator
position (
in accordance with EN12053)
(only 3B Machine)
74 dB
Guaranteed sound power level LwA
(in accordance with the Directive 2000/14/CE)
(only 3B Machine)
102 dB
Floor loading information
Tire load, maximum 10,500 kg
Occupied floor pressure 20.32 kPa
