May 2015
64 GTH 4016 R - GTH 4018 R - GTH-5021 R Part No. 57.0009.0607
Second Edition - First Printing
Functions joystick with
enable switch (B)
Functions joystick with
enable switch (B) and
yellow roller switch (D)
Functions joystick with
enable switch (B) and
yellow roller switch (C)
D
D
D
C
Controller movements - Single
Functions Joystick
Lock or unlock hydraulic quick coupling by
simultaneously pressing hydraulic quick
coupling lock/unlock switch, functions
joystick enable button (B) and white thumb
button (A)
Hydraulic quick coupling (if equipped)
Operating Instructions
