Terex Genie GTH-4016 R User Manual

May 2015Second Edition - First Printing
Part No. 57.0009.0607 GTH 4016 R - GTH 4018 R - GTH-5021 R 65
Controller movements - Dual
Functions Joysticks (if equipped)
D
D
D
( )
( )
Functions joystick only
with red finger switch
(B)
Functions joystick only
with red finger switch
(B) and with yellow
roller switch (D)
Functions joystick only
with red finger switch
(B)
Operating Instructions
While pressing the hydraulic quick
coupling lock/unlock, functions joystick
with red finger switch (B) and with white
thumb switch (A)
