5.3 Starting Procedure
Before starting the engine, perform the pre-operation safety checklist. Once com-
plete, you may proceed by following this procedure:
1. Enter machine with lift arms all the way down. Maintain three points of
contact with the machine (fig. 5.3-1).
2. Sit down into the operator’s seat, fasten seat belt, then lower lap bar into
position.
3. Starting with the throttle in the SLOW (turtle icon) position, push the throttle
1/3 the way open (toward the rabbit icon).
4. Turn the ignition key to the left for 6 seconds to “pre-heat” the engine.
While pre-heating, the glow plug operation light will illuminate.
5. Turn the ignition key to the right to start the engine.
6. Once running, reduce throttle to a low idle by pulling back on the hand
lever. Let the engine run at low idle for 2 to 3 minutes to warm it.
7. Set desired engine speed (RPM) by moving the throttle forward.
Note: The parking brake is automatically engaged when the machine is turned
off.
5 OPERATION
48
5.3-1 5.3-2
Entering or exiting the vehicle under raised lift arms could result in injury
or death. Never allow anyone beneath raised, unsecured lift arms
(fig. 5.3-2).
