5.10 Unfastening Attachments
1. Lower the lift arms so that the
attachment is just barely off of the
ground.
2. Pull the locking levers on the quick
attach mechanism upwards and
toward the outside of the machine to
unlock the attachment.
3. Lay the attachment gently onto the
ground by moving the lift arm control
joy stick slowly to the right.
4. Once the attachment is in contact
with the ground, move the lift arm
control joystick gently to the right
until the quick-attach is clear of the
attachment.
5. Back the machine away from the
attachment.
5 OPERATION
52
5.10-1
5.10-2
5.10-3
un-lock
lock
