Terex RL4000 Service Manual

Section 5 • Schematics
5 - 8 RL4000 • TML-4000 Part No. 116694
June 2013
1000 MH Ballast
Drawing #2986
INPUT 120V
INPUT COMMON
LAMP HOT
LAMP COMMON
GROUND
COM
GRN
WHITE
5-POLE
RECEPTACLE
RED
C1
24mF
480V
BLACK
WHITE
RED
ORANGE
GREEN
COLOR
ORANGE
BLACK
120V
TRANSFORMER
(1000W METAL HALIIDE BALLAST)
CAPACITOR
CIRCUIT
Discount-Equipment.com

Terex RL4000 Specifications

General

Number of Lights	4
Fuel Type	Diesel
Mast Height	9 m (30 ft)
Light Type	LED
Lamps	LED
Illuminated Area	4000 m²
