Section 5 • Schematics
Part No. 116694 RL4000 • TML-4000 5 - 3
June 2013
P1
E-STOP
(OPTION)
TEMPERATURE
SWITCH
GLOW PLUGS
FUEL PUMP
GROUND
FUEL SOLENOID
STARTER
SOLENOID
STARTER
SOLENOID
STARTER
BATT +
ALTERNATOR
(IG)
ALTERNATOR
(B+)
OIL PRESSURE
SWITCH
FUSE
30A
Engine Harness, Kubota
Drawing #116820B
