Operating Manual Crawler Excavator TC37
Introduction1
1.5 Pictograms
The following Table explains the meaning of the
pictograms which may be attached to your machine.
Symbol Description Symbol Description
Danger to life Windshield washer and wiper system
On machine:
Caution, safety distance
In Operating Instructions:
Danger of injury/machine damage
Travel speed, FAST
Attention Travel speed, SLOW
Battery charge indicator Horn
Preheating Working floodlight(s)
Engine oil pressure Rotating beacon
Engine oil level Dozer blade
Coolant temperature Hydraulic rock breaker
Air filter Working hydraulics shut-off
Fuel, fuel level Fire extinguisher
Hydraulic oil
Hydraulic oil level
Danger of injury
Hydraulic oil filter clogging indicator Observe notes in Operating Instructions
Fan for heating/ventilation Grease gun
Air conditioning system
Tab. 1 Pictograms on the machine
