34
Operating Manual Crawler Excavator TC37
Technical Specifications3
3.10 Carrying capacity
The stated carrying capacities in tons (t) were
determined according to ISO 10567 and include a
stability factor of 1.33 or 87% of the hydraulic lifting-
load capacity.
Carrying capacity tables with the following
equipment:
–boom
– 63.00 in dipperstick with quick-attach system
– without bucket
– rubber crawler chain, 11.81 in wide
– full tank, with driver
Attention
The dead-weight of the work attachment
must be deducted from the stated payload.
Permissible values Load radius from center of ring gear in foot
8.20 9.84 11.48 13.12 14.76
longt. trans-
verse
longt. trans-
verse
longt. trans-
verse
longt. trans-
verse
longt. trans-
verse
Height
Bucket pivot
height
in foot
6.56
A - - 2536 1764 2139 1411 2051 1103 1896 816
V - - 2161 1742 1720 1367 1367 1058 1125 860
3.28
A 4212 2315 3175 1720 2646 1345 2271 1058 1918 882
V 4079 2249 2051 1676 1632 1301 1323 1036 1103 860
0.0
A 4498 2094 3550 1566 2690 1235 2161 1014 1764 838
V 4410 2028 1896 1544 1455 1213 1257 992 1080 816
Tab. 13 Table of carrying capacity in pounds
A) supported by dozer blade
V) movable
