52
Operating Manual Crawler Excavator TC37
Recovery, Loading and Transporting5
5.3 Transport
• During transport on a flat bed trailer, by truck and
rail, etc., the machine must be properly lashed at
the marked points (chassis 25/1 and dozer blade
25/2) and be secured with chocks.
• Lower the dozer blade and position the work
equipment on the ground.
Loading the machine onto a truck (Fig. 26)
• Connect the loading platform (ramp) to the
excavator (max. angle 15°).
• Secure the machine to be loaded with chocks
against rolling away.
• Drive the machine in reverse onto the truck and
drive it forward when unloading it from the truck.
• Carefully lash the machine for transport.
Fig. 25 Lashing the machine
Fig. 26 Loading the machine onto a truck
Danger to life
due to disregarding the total transport height.
• Be aware of the total clearance height
when driving in tunnels, under bridges, etc.
