Operating Manual Crawler Excavator TC37
Technical Specifications 3
3.9 Dimensions and operating weights
1
Weight Excavator equipment
Operating weight according to ISO 6016:
with 15.75 in bucket, quick-attach system,
control circuit for work attachments, open
return, rubber crawler chains, including driver,
full fuel tank
8048 lbs Dipperstick 63.00 in
Extra-long dipperstick (option) 70.88 in
Transport weight with tank half full, w/ quick-
attach system, w/out bucket
7607 lbs Dig depth 124.05 in
Cab 374 lbs Deepest bucket hinge point 92.94 in
Canopy 176 lbs Maximum possible height 179.18 in
Dimensions Dump height 120.50 in
Total width of undercarriage/dozer blade 69.31/
69.31 in
Maximum height of bucket hinge point 151.61 in
Total width of uppercarriage 63.00 in maximum reach 217.38 in
Total length (travel position) 125.23 in Bucket angle of rotation 185°
Total height (travel position) 127.99 in Ripping force
1
3641 lbf
Height (cabin roof) 98.06 in Breakout force
1
5530 lbf
Uppercarriage tail swing 35.44 in
Ground clearance 11.81 in
Drawbar pull, 1st speed range 3100 daN
Drawbar pull, 2nd speed range 1600 daN
Tab. 12 Dimensions and operating weights
1
Values are theoretical according to DIN 24086.
