Page 10 of 20
If the option is set to ‘Off’ the interval distance will not zero when FRZ is pressed.
Selection is shown by a solid dot next to the option (on/off). Press ENTER to change
the selection, MENU exits the settings menu.
8.4 Set AVS Times:
Note: This option is only for 303 models with the remote display fitted. This option
allows you to change the average speed indicator times on the optional remote
display (Part No. T016G), so that it can be adjusted to your preferences.
When AVS is turned on, the LEDs on the remote display show target timing in
seconds. The LEDs displayed relate to your target average speed error in seconds as
set below.
Example: If target speed/time is within +/-1s of the calculated time then just the Green
LED will be lit. If then the driver slows down, and the target time goes greater than 3
seconds, the first yellow LED to the left of the Green LED will also light. If the driver
is still driving slower than the calculated target, and the target time goes greater than 6
seconds, the 2nd yellow LED’s to the left of the green LED will be lit. This continues
until the target time goes over 15seconds where all the LED’s to the left of the Green
LED will be lit.
If the driver is driving faster than the target speed then the exact same will happen
except that the LED’s will illuminate to the right of the Green LED to indicate that the
speed is greater than calculated.
The display shows:
Green : +/-01s
1
s
Yellow : +/-03s
2
n
Yellow : +/-06s
Red : +/-15s
Press ENTER on the relevant line to set the time in seconds after which the relevant
LED will light up. Use the number keys to enter the time, and press ENTER once
more to set, or the upper CLR to cancel editing.
9.0 GPS Options:
The GPS menu will not be accessible unless the GPS module is fitted. Please refer to
‘Fitting GPS module’ if you are fitting a module to an existing GeoTrip®.
9.1 Start Threshold:
Start threshold is the speed at which the GPS probe will start recording distance.
