6.1 Select Cal:
The display shows the current calibration by placing a solid dot next to the selected
calibration figure.
Select Cal : ●-CAL 1
○-CAL 2
*(CAL 1 is selected)
Press ENTER to switch between calibration figures, and MENU to exit.
6.2 Auto Cal:
Auto cal can be used to calibrate the unit from a set distance, e.g. a measured mile or
kilometre or a calibration distance from a road-book.
Note: If the GPS probe is selected, the unit will exit auto calibration automatically.
You do not need to calibrate the GPS!
How to use auto calibration:
1. Press MENU.
2. Select CALIBRATION then press ENTER.
3. Select Auto Cal.
4. The auto calibration screen displays ‘00000’.
5. Press ENTER and start to drive.
6. The display will show ‘Now drive to set distance’ briefly and shows an
animated arrow running across the screen. If there is no pulses being received
from the probe, or the incorrect probe is selected the figure will remain at
00000. If this is the case, you need to exit auto calibration and select a
different probe using KEY 8 (Probe).
7. Press ENTER at the end of the measured distance, and the unit will prompt
you to enter the distance driven. E.g. if you have driven 1.2km, enter 0120
using the number keys. Then press ENTER.
8. The display will now show the calibration figure that has been calculated from
the driven distance. Press ENTER to accept the calibration to the shown figure
or MENU to exit, and leave calibration as it was previously.
6.3 Manual Cal:
If you know the calibration figure (impulses per kilometre or mile) for your vehicle
then you can enter the figure manually.
The Manual Calibration screen will show the current calibration number, and
calibration value followed by 00000.Use the number keys to enter a value i.e. if the
calibration value is 1540, press 1, 5, 4, 0 then ENTER. If a mistake is made, the digits
will scroll, so entering 0, 1, 5, 4, 0 will reset all the digits shown to 01540.
To exit the menu without setting a calibration, figure press the upper CLR.
