16
FAULT lighting indicates mode code, fault code and warning code,
which could be displayed from 0 to99 ,SET lighting indicates the set
code, type V (set voltage), F (set frequency)
BATTERY lighting indicates the battery voltage value, which could
be displayed from 0 to 999Vdc; TEMP lighting indicates the ups
inside temperature, which could be displayed from 0 to 999℃(The
two items alternate displayed once every three seconds.)
indicates the battery capacity. For example: 25% and 50% lighting
synchronous, it means current battery capacity is 50%. LOW BAT
lighting indicates the battery is weak, and the UPS should shut down
soon,BATTERY FAULT lighting indicates
indicates the present load value. For example: 25% and 50% lighting
synchronous, it means current load is 50%. When load 100%
lighting and the OVER LOAD lighting with warning, it means ups in
overload
Indicates ups input voltage value, output voltage value, output
frequency value, which could be displayed from 0 to 999VAC (The
four items alternate displayed once every three seconds.) 208,
220 ,230,240VAC The four value of the output voltage could be
selected, 50/60HZ the two frequency value of the output voltage
could be selected.
indicates have mains power and when mode code display 02 that
mean the ups working in Line mode. ECO lighting indicates ups
working in ECO Mode. lighting indicates ups charging， lighting and
mode code display 03 that mean the ups working in battery mode.
and lighting coinstantaneous and mode code display 03 that means
UPS working in Bypass mode. and LOW BAT lighting
coinstantaneous and UPS with warning that means Battery low
voltage, the ups will would shut down soon. 。
