5 Display and control elements
18
Representation Explanation
Yellow LED
flashes three
times
Instrument changes from Wait-mode to
Rec-mode.
Yellow LED
flashes three
times when
pressing the
button
Instrument is in Rec-mode
Green and
yellow LED flash
three times when
pressing the
button.
Instrument is in End-mode
Green LED
flashes three
times when
pressing the
button
Instrument is in Wait-mode
Green LED
flashes five times
when pressing
the button
Long pressing of the GO button has set
a time mark.
Green, yellow
and red LED
flash in
succession
The battery has been changed.
5.3. Key functions
A detailed representation of the display readings can be
found under Menu overview page 20.
✓ Instrument in operating status Wait and start criterion
Button start programmed.
> Press [GO] for approx. 3 seconds to start the
measurement program.
- The measurement program starts and Rec appears in
the display.
✓ Instrument is in operating status Wait:
> Press [GO] in order to change between displays of
upper alarm value, lower alarm value, battery life and
last reading.
