• Connect the 3-phase AC output terminals located at the wind turbine output to the
charge control unit with battery-inverter input and make sure to screw the terminals
tightly.
• If you are using your charge control unit in ‘Battery’ mode, you should adjust the
maximum voltage with the help of the potentiometer on it. (The maximum voltage
setting is made to protect the system and to activate the automatic braking system
when the wind speed reaches the capacity to produce the voltage value we have
determined. Maximum voltage value should not exceed 18V for a 12V system, 30V for a
24V system, and 58V for a 48V system.
WARNING:
- Danger to life due to operation in non-approved wind classes! The
wind turbine system may only be operated up to Class III wind sites.
- High Wind Speed - High Voltages - High Temperatures
- Fire Resistant Cables Only
- OUTDOOR USE ONLY
IMPORTANT: To make the system operational TESUP Wind
Turbine, TESUP Charge Controller and TESUP selling grid inverter
are all required. All to be installed outdoors.
WARNING: The mounting base of the wind turbine must be xed
to the mounting surface and checked that it is fully stable, before
moving on to the next steps with wind turbine installation.
22TESUP Electronics Ltd. All rights reserved. ©2023 | www.tesup.com
7. Pre-use
Preperation
HERA WIND PRO USER MANUAL
