WARNING: All work on electrical equipment must be carried out
by a qualied electrician with the power switched off!
NOTE: To ensure proper operation, you must use an original TESUP
charge controller.
7.7 ELECTRICAL CONNECTIONS
Wind Turbine has 3 phase AC connection. These connections
are to be connected with TESUP Charge Controller.
The output of the charge controller can be then connected in
two ways:
• The Output of the charge controller can be connected to
the battery.
• The Output of the charge controller can be connected to
the power grid using the inverter.
The cables from charge controller to the battery or the power
grid will be DC connection.
Cable lengths and cross sections should be as follows.
Scan to watch electrical
connections
Length <11 m <18 m <29 m <44 m <68 m <110 m
Cross-section
2.5 sq.
mm
4 sq.
mm
6 sq.
mm
10 sq.
mm
16 sq.
mm
25 sq.
mm
