TESVOLT TS 48V - Page 49

exPANdINg The sTORAge sysTeM 49
© TESVOLT We reser ve the right to make technical changes. Version RD.TI.015.E.ENG_Installation_Manual_TS48V_v.C.01 Last revised 06/2020
System with one master and two slaves
Master Slave 2
TERM
ON OFF
ADDRESS
BATTERY
CHARGER
TERM
ON OFF
ADDRESS
TERM: ON
ADDRESS: 2/1
CAN IN > CAN OUT Slave 1
CAN IN CAN OUT CAN SMA LAN
APU configuration for Slave 2
Slave 1
TERM: OFF
ADDRESS: 2/0
CAN IN > CAN OUT Master
CAN OUT > CAN IN Slave 2
TERM
ON OFF
CAN IN CAN OUT CAN SMA LAN
ADDRESS
APU configuration for Slave 1
BATTERY
CHARGER
TS 48 V TS 48 V
SMA Sunny Islands
Bat Fuse B03
APU configuration for Master
TERM: ON
ADDRESS: 0/0
CAN OUT > CAN IN Slave 1
CAN SMA > ComSync IN
LAN > SWITCH
TS 48 V
CAN IN CAN OUT CAN SMA LAN
BATTERY
CHARGER
