-6-
FRONT PANEL REFERENCE
1. Standby button
2. OPEN/CLOSE button
3. SKIP- button
4. Stop button
5. Play button
6. SKIP+ button
7. PAUSE button
8. VFD Display
Displays the relevant working status
9. Remote control sensor
10. Disc tray
11. Slot for SD/SM/MMC/MS cards
12. Slot for CF I/II cards
13. Card reader working indicator
14. Headphone jack
15. Headphone volume knob
