-7-
REAR PANEL REFERENCE
1. 5.1 Channel Front Left output
2. 5.1 Channel Surround Left output jack
3. 5.1 Channel Center output jack
4. S-video output jack
5. Video output
6. 5.1 Channel Subwoofer output jack
7. 5.1 Channel Surround Right output jack
8. 5.1 Channel Front Right output
9. Coaxial output jack
Outputs a digital audio signal and can be connected to a digital audio decoder or amplifier with
coaxial input
10. 2CH Audio LEFT output jack
11. 2CH Audio RIGHT output jack
12. Optical output jack
Outputs a digital audio laser signal for greater clarity and can be connected directly to an optical
audio decoder or amplifier input.
13. Chromatic signal Y-axis output jack
14. Chromatic signal Cb/Pb output jack
15. Chromatic signal Cr/Pr output jack
16. Europe 21 pin SCART output (with R, G, B signal)
17. POWER switch
18. AC POWER cord
