11 INSTALLATION
The following chapters describe the device's installation phases.
Please read this manual thoroughly before proceeding with the installation.
The installation must:
•
be performed by qualified personnel;
•
be carried out following the indications provided in the
specific installation sheet for the vehicle you are
working on.
For the installation you need:
•
Scissors and a wire stripper.
•
Flat-tip and Phillips screwdriver (medium).
•
A 12 mm hole saw for the hole, if required, needed to pass the wiring cable from the
engine compartment to the passenger compartment.
•
A 5 mm drilling tip for the assembly screws.
•
Plastic cable ties.
•
Pliers for cable terminals.
•
Square tip pliers.
•
PC connected to Internet in order to program the device.
In the installation, the following wirings are used:
Wiring Code Quantity
Power supply 3907865 1
The installation requires the following phases:
1.
Reading of the installation and user manual.
2.
Planning and positioning of the device.
3.
Power supply connections.
4.
Connection of the wiring to the device.
5.
Configuration.
