Table 5. BQ24800EVM Bill of Materials (continued)
Designator Qty Value Description Package
Reference
PartNumber Manufacturer
R6, R7 2 3.9 RES, 3.9, 5%, 0.5 W, 1210 1210 ERJ-14YJ3R9U Panasonic
R8 1 6.8 RES, 6.8, 5%, 0.1 W, AEC-Q200 Grade 0,
0603
0603 CRCW06036R80JNEA Vishay-Dale
R10 1 66.5k RES, 66.5 k, 1%, 0.1 W, AEC-Q200 Grade 0,
0603
0603 CRCW060366K5FKEA Vishay-Dale
R12, R15 2 0 RES, 0, 5%, 0.1 W, AEC-Q200 Grade 0,
0603
0603 CRCW06030000Z0EA Vishay-Dale
R13, R14, R16 3 4.02k RES, 4.02 k, 1%, 0.1 W, AEC-Q200 Grade 0,
0603
0603 CRCW06034K02FKEA Vishay-Dale
R17, R20, R21 3 10.0 RES, 10.0, 1%, 0.1 W, 0603 0603 RC0603FR-0710RL Yageo
R19 1 10.0 RES, 10.0, 1%, 0.25 W, AEC-Q200 Grade 0,
1206
1206 ERJ-8ENF10R0V Panasonic
R22 1 316k RES, 316 k, 1%, 0.1 W, AEC-Q200 Grade 0,
0603
0603 CRCW0603316KFKEA Vishay-Dale
R23, R24, R25, R26, R27,
R30, R32, R34, R35
9 10.0k RES, 10.0 k, 1%, 0.1 W, AEC-Q200 Grade 0,
0603
0603 CRCW060310K0FKEA Vishay-Dale
R28 1 499k RES, 499 k, 1%, 0.1 W, AEC-Q200 Grade 0,
0603
0603 CRCW0603499KFKEA Vishay-Dale
R29 1 140k RES, 140 k, 1%, 0.1 W, AEC-Q200 Grade 0,
0603
0603 CRCW0603140KFKEA Vishay-Dale
R31, R37 2 100k RES, 100 k, 5%, 0.1 W, AEC-Q200 Grade 0,
0603
0603 CRCW0603100KJNEA Vishay-Dale
R36 1 49.9k RES, 49.9 k, 1%, 0.1 W, AEC-Q200 Grade 0,
0603
0603 CRCW060349K9FKEA Vishay-Dale
R38 1 30.1k RES, 30.1 k, 1%, 0.1 W, AEC-Q200 Grade 0,
0603
0603 CRCW060330K1FKEA Vishay-Dale
R39, R40, R41, R42 4 2.00k RES, 2.00 k, 1%, 0.1 W, AEC-Q200 Grade 0,
0603
0603 CRCW06032K00FKEA Vishay-Dale
TP1, TP3, TP5 3 Test Point, Miniature, Red, TH Red Miniature
Testpoint
5000 Keystone
TP2, TP4, TP6 3 Test Point, Compact, SMT Testpoint_Keyston
e_Compact
5016 Keystone
TP7, TP8, TP9, TP10,
TP11, TP12, TP13, TP14,
TP15, TP16, TP17, TP18,
TP19, TP20, TP21, TP23
16 Test Point, Miniature, White, TH White Miniature
Testpoint
5002 Keystone
TP22 1 Test Point, Miniature, Orange, TH Orange Miniature
Testpoint
5003 Keystone
TP24 1 Test Point, Miniature, Black, TH Black Miniature
Testpoint
5001 Keystone
U1 1 1- to 4-Cell Hybrid Power Boost Mode Battery
Charge Controller With Battery Only Boost
Mode and Power Monitoring, RUY0028A
(WQFN-28)
RUY0028A BQ24800RUYR Texas Instruments
U2 1 Single Channel, Ultra Small, Adjustable
Supervisory Circuit with Active-Low, Open-
Drain Output, 1 Supply Monitored, -40 to 125
degC, 6-pin SON (DRY), Green (RoHS & no
Sb/Br)
DRY0006A TPS3898ADRYR Texas Instruments
U3 1 150-mA, 30-V, Ultra-Low IQ, Wide Input Low-
Dropout Regulator with Reverse Current
Protection, DRV0006A (WSON-6)
DRV0006A TPS70933DRVR Texas Instruments
C13, C21, C30 0 0.1µF CAP, CERM, 0.1 µF, 25 V, ±10%, X7R, 0603 0603 C1608X7R1E104K080AA TDK
C18 0 1µF CAP, CERM, 1 µF, 25 V, ±10%, X7R, 0603 0603 C1608X7R1E105K080AB TDK
C24, C25 0 10µF CAP, CERM, 10 µF, 25 V, ±10%, X7R,
1206_190
1206_190 TMK316B7106KL-TD Taiyo Yuden
C38 0 100pF CAP, CERM, 100 pF, 50 V, ±5%, C0G/NP0,
0603
0603 GRM1885C1H101JA01D MuRata
D1, D3 0 30V Diode, Schottky, 30 V, 0.2 A, SOD-323 SOD-323 BAT54HT1G ON Semiconductor
D2 0 20V Diode, Schottky, 20 V, 1 A, SMA SMA SS12-E3/61T Vishay-
Semiconductor
D6 0 8.2V Diode, Zener, 8.2 V, 500 mW, SOD-123 SOD-123 BZT52C8V2-7-F Diodes Inc.
FID1, FID2, FID3, FID4,
FID5, FID6
0 Fiducial mark. There is nothing to buy or
mount.
N/A N/A N/A
H1 0 Machine Screw, Round, #4-40 x 1/4, Nylon,
Philips panhead
Screw NY PMS 440 0025 PH B&F Fastener
Supply
R11 0 100k RES, 100 k, 1%, 0.1 W, AEC-Q200 Grade 0,
0603
0603 CRCW0603100KFKEA Vishay-Dale
