After completing the previous steps, the test setup for BMS031 appears as shown in Figure 2.
Figure 2. Original Test Setup for BQ24800 EVM (BMS031)
Turn on the computer. Launch the bqstudio evaluation software and select charger and BQ24800. And
then click the Registers button. The main window of the BQ24800 software is shown in Figure 3.
Figure 3. Main Window of BQ24800 Evaluation Software
