Board Layout, Schematic, and Bill of Materials
15
SLUUC60–February 2020
Submit Documentation Feedback
Copyright © 2020, Texas Instruments Incorporated
BQ24800 EVM
5.3 Bill of Materials
Table 5 lists the BQ24800EVM BOM.
Table 5. BQ24800EVM Bill of Materials
Designator Qty Value Description Package
Reference
PartNumber Manufacturer
!PCB1 1 Printed Circuit Board BMS031 Any
C1 1 0.01µF CAP, CERM, 0.01 µF, 25 V, ±5%, C0G/NP0,
0603
0603 C0603H103J3GACTU Kemet
C2 1 1000pF CAP, CERM, 1000 pF, 25 V, ±10%, X7R,
0402
0402 885012205044 Wurth Elektronik
C3 1 47µF CAP, TA, 47 µF, 25 V, ±10%, 0.125 ohm,
SMD
7343-31 TPSD476K025R0125 AVX
C4, C5 2 22µF CAP, CERM, 22 µF, 25 V, ±20%, X5R,
1206_190
1206_190 C3216X5R1E226M160AB TDK
C6, C20 2 1µF CAP, CERM, 1 µF, 25 V, ±10%, X7R, AEC-
Q200 Grade 1, 0603
0603 GCM188R71E105KA64D MuRata
C7, C8, C22, C23 4 10µF CAP, CERM, 10 µF, 25 V, ±10%, X7R,
1206_190
1206_190 TMK316B7106KL-TD Taiyo Yuden
C9 1 22µF CAP, CERM, 22 µF, 25 V, ±10%, X5R, 1210 1210 CL32A226KAJNNNE Samsung Electro-
Mechanics
C10 1 2.2µF CAP, CERM, 2.2 µF, 25 V, ±10%, X5R, 1206 1206 12063D225KAT2A AVX
C11, C16, C19, C26, C28,
C29
6 0.1µF CAP, CERM, 0.1 µF, 25 V, ±5%, X7R, 0603 0603 C0603C104J3RACTU Kemet
C12, C31 2 0.01µF CAP, CERM, 0.01 µF, 50 V, ±10%, X7R,
0603
0603 C0603X103K5RACTU Kemet
C14 1 1000pF CAP, CERM, 1000 pF, 50 V, ±10%, X7R,
0603
0603 CL10B102KB8NNNC Samsung Electro-
Mechanics
C15, C17 2 0.047µF CAP, CERM, 0.047 µF, 50 V, ±10%, X7R,
AEC-Q200 Grade 1, 0603
0603 CGA3E2X7R1H473K080AA TDK
C27 1 470pF CAP, CERM, 470 pF, 50 V, ±10%, X7R, 0603 0603 C0603C471K5RACTU Kemet
C32 1 2.2µF CAP, CERM, 2.2 µF, 16 V, ±10%, X7R, 0603 0603 EMK107BB7225KA-T Taiyo Yuden
C33 1 2200pF CAP, CERM, 2200 pF, 50 V, ±10%, X7R,
0805
0805 08055C222KAT2A AVX
C34 1 0.1µF CAP, CERM, 0.1 µF, 25 V, ±10%, X7R, 0603 0603 C0603C104K3RACTU Kemet
C35 1 1µF CAP, CERM, 1 µF, 35 V, ±20%, X5R, 0402 0402 GRM155R6YA105ME11D MuRata
C36 1 2.2µF CAP, CERM, 2.2 µF, 10 V, ±20%, X5R, 0402 0402 885012105013 Wurth Elektronik
C37, C39 2 100pF CAP, CERM, 100 pF, 50 V, ±5%, C0G/NP0,
0603
0603 GRM1885C1H101JA01D MuRata
D4, D5 2 30V Diode, Schottky, 30 V, 0.2 A, SOD-323 SOD-323 BAT54HT1G ON Semiconductor
D7, D8, D9, D10 4 Green LED, Green, SMD 1.6x0.8x0.8mm LTST-C190GKT Lite-On
H2, H3, H4 3 Machine Screw, Round, #4-40 x 1/4, Nylon,
Philips panhead
Screw NY PMS 440 0025 PH B&F Fastener
Supply
H5, H6, H7, H8 4 Standoff, Hex, 0.5"L #4-40 Nylon Standoff 1902C Keystone
J1, J2, J3 3 Terminal Block, 5.08 mm, 2x1, Brass, TH 2x1 5.08 mm
Terminal Block
ED120/2DS On-Shore
Technology
J4 1 Terminal Block, 3.5mm Pitch, 3x1, TH 10.5x8.2x6.5mm ED555/3DS On-Shore
Technology
J5 1 Header (friction lock), 100mil, 4x1, R/A, TH 4x1 R/A Header 22/05/3041 Molex
JP1, JP2, JP3, JP4, JP5 5 Header, 100mil, 2x1, Gold, TH Header, 2x1,
100mil
5-146261-1 TE Connectivity
L1 1 3.3µH Inductor, Shielded, Powdered Iron, 3.3 µH,
9.2 A, 0.0177 ohm, SMD
322x158x322mil IHLP3232DZER3R3M01 Vishay-Dale
LBL1 1 Thermal Transfer Printable Labels, 0.650" W
x 0.200" H - 10,000 per roll
PCB Label 0.650 x
0.200 inch
THT-14-423-10 Brady
Q1 1 50V MOSFET, N-CH, 50 V, 0.2 A, SOT-323 SOT-323 BSS138W-7-F Diodes Inc.
Q2, Q3, Q4, Q5, Q6 5 30V MOSFET, N-CH, 30 V, 47 A, DQG0008A
(VSON-CLIP-8)
DQG0008A CSD17308Q3 Texas Instruments
Q7 1 60V MOSFET, N-CH, 60 V, 0.26 A, SOT-23 SOT-23 2N7002ET1G ON Semiconductor
R1, R33 2 1.00Meg RES, 1.00 M, 1%, 0.1 W, AEC-Q200 Grade
0, 0603
0603 CRCW06031M00FKEA Vishay-Dale
R2 1 3.01Meg RES, 3.01 M, 1%, 0.1 W, AEC-Q200 Grade
0, 0603
0603 CRCW06033M01FKEA Vishay-Dale
R3, R9 2 0.01 RES, 0.01, 1%, 1 W, 1206 1206 WSLP1206R0100FEA Vishay-Dale
R4 1 430k RES, 430 k, 1%, 0.1 W, 0603 0603 RC0603FR-07430KL Yageo
R5 1 4.7 RES, 4.7, 5%, 0.1 W, AEC-Q200 Grade 0,
0603
0603 CRCW06034R70JNEA Vishay-Dale
