Table 2-4. J2 Connector
(1)
Analog
Tiva C
GPIOPCTL Register Setting
Function
J2 On-board Series
GPIO
Pin Function MCU
GPIO
1 2 3 4 5 6 7 8 9 14 15
Pin
AMSEL
2.01 GND
2.02 PB2 – – 47 – – I2C0SCL – – – T3CCP0 – – – –
2.03 PE0 AIN3 – 9 U7Rx – – – – – – – – – –
2.04 PF0 – USR_SW2/ 28 U1RTS SSI1Rx CAN0Rx – M1PWM4 PhA0 T0CCP0 NMI C0o – –
WAKE (R1)
2.05 RESET
PB7 – – 4 – SSI2Tx – M0PWM1 – – T0CCP1 – – – –
PD1 AIN6 Connected 62 SSI3Fss SSI1Fss I2C3SDA M0PWM7 M1PWM1 – WT2CCP1 – – – –
2.06
for MSP430
Compatibility
(R10)
PB6 – – 1 – SSI2Rx – M0PWM0 – – T0CCP0 – – – –
PD0 AIN7 Connected 61 SSI3Clk SSI1Clk I2C3SCL M0PWM6 M1PWM0 – WT2CCP0 – – – –
2.07
for MSP430
Compatibility
(R9)
2.08 PA4 – – 21 – SSI0Rx – – – – – – – – –
2.09 PA3 – – 20 – SSI0Fss – – – – – – – – –
2.10 PA2 – – 19 – SSI0Clk – – – – – – – – –
(1)
Shaded cells indicate configuration for compatibility with the MSP430 LaunchPad.
Table 2-5. J3 Connector
(1)
Analog
Tiva C
GPIOPCTL Register Setting
Function
J3 On-board Series
GPIO
Pin Function MCU
GPIO
1 2 3 4 5 6 7 8 9 14 15
Pin
AMSEL
3.01 5.0 V
3.02 GND
PD0 AIN7 – 61 SSI3Clk SSI1Clk I2C3SCL M0PWM6 M1PWM0 – WT2CCP0 – – – –
PB6 – Connected 1 – SSI2Rx – M0PWM0 – T0CCP0 – – – –
3.03
for MSP430
Compatibilit
y (R9)
PD1 AIN6 – 92 SSI3Fss SSI1Fss I2C3SDA M0PWM7 M1PWM1 – WT2CCP1 – – – –
PB7 – Connected 4 – SSI2Tx – M0PWM1 – – T0CCP1 – – – –
3.04
for MSP430
Compatibilit
y (R10)
3.05 PD2 AIN5 63 SSI3Rx SSI1Rx – M0FAULT0 – – WT3CCP0 USB0EPE
N
3.06 PD3 AIN4 – 64 SSI3Tx SSI1Tx – – – – WT3CCP1 USB0PFLT – – –
3.07 PE1 AIN2 – 8 U7Tx – – – – – – – – –
3.08 PE2 AIN1 – 7 – – – – – – – – – – –
3.09 PE3 AIN0 – 6 – – – – – – – – – – –
3.10 PF1 – – 29 U1CTS SSI1Tx – – M1PWM5 – T0CCP1 – C1o TRD1 –
(1)
Shaded cells indicate configuration for compatibility with the MSP430 LaunchPad.
