Texas Instruments EK-TM4C123GXL

Bill of Materials (BOM) www.ti.com
Table 4-1. EK-TM4C123GXL Bill of Materials (continued)
Item Ref Des Qty Description Manufacturer Manufacturer Part No
12 J11 1 USB Connector, Micro B Recept Hirose ZX62-B-5PA
RA SMT BTTM MNT
13 J2, J4 2 Header, 1x2, 0.100, SMT, Samtec TSM-110-01-S-DH-A-P-TR
Horizontal Unshrouded, 0.230
4UCON 10995
Mate
Major League TSHSM-110-D-02-T-H-AP-
Electronics TR-P-LF
14 J9 1 USB Connector, Micro A/B Hirose ZX62-AB-5PA
Receptacle SMD
15 Q1-3 3 NPN SC70 pre-biased Diodes Inc DTC114EET1G
16 R1-2, R9-16, R20, 12 Resistor, 0 Ω 1/10W 0603 SMD Panasonic ERJ-3GEY0R00V
R26
17 R18-19, R21-23, R28 6 Resistor, 10 kΩ, 1/10W, 5%, 0402 Yageo RC0402FR-0710KL
Thick Film
18 R3-5, R8, R27 5 Resistor, 330 Ω, 1/10W, 5%, 0402 Yageo RC0402FR-07330RL
19 R31 1 Resistor, 1 MΩ 1/10W, 5%, 0402 Rohm MCR01MRTF1004
20 RESET SW1, SW2 3 Switch, Tact 6 mm SMT, 160gf Omron B3S-1000
21 SW3 1 Switch, DPDT, SMT 300 mA × 2 at C K Components JS202011SCQN
6 V
22 U1, U2 2 Tiva C Series MCU Texas Instruments TM4C123GH6PMI
TM4C123GH6PM
23 U8 1 Regulator, 3.3 V, 400 mA, LDO Texas Instruments TPS73633DRBT
24 Y1 1 Crystal, 32.768 kHz Radial Can Abracon AB26TRB-32.768KHZ- T
25 Y2, Y5 2 Crystal, 16.00 MHz 5.0x3.2mm NDK NX5032GA-16.000000 MHz
SMT
Abracon ABM3-16.000 MHz-B2- T
PCB Do Not Populate List
(Shown for information only)
26 C31, C34 2 Capacitor, 0.1 μF 16 V, 10% 0402 Taiyo Yuden EMK105B7104KV-F
X7R
27 D2 1 Diode, Dual Schottky, SC70, Diodes Inc BAS70W-05-7-F
BAS70 Common Cathode
28 R17 1 Resistor, 10 kΩ 1/10W 5%, 0402 Yageo RC0402FR-0710KL
Thick Film
29 R24 1 Resistor, 330 Ω, 1/10W, 5%, 0402 Yageo RC0402FR-07330RL
30 R25, R29-30 3 Resistor, 0 Ω, 1/10W 0603 Panasonic ERJ-3GEY0R00V
31 U4 1 IC, Single Voltage Supervisor, 5V, Texas Instruments TLV803MDBZR
DBV
18
References, PCB Layout, and Bill of Materials SPMU296–April 2013
