Table 5-8. Interrupt NVM Settings (continued)
Register Name Field Name
TPS65941213-Q1 TPS65941111-Q1
Value Description Value Description
MASK_GPIO1_8_RISE GPIO1_RISE_MASK 0x1 Interrupt not generated. 0x1 Interrupt not generated.
GPIO2_RISE_MASK 0x1 Interrupt not generated. 0x0 Interrupt generated
GPIO3_RISE_MASK 0x1 Interrupt not generated. 0x1 Interrupt not generated.
GPIO4_RISE_MASK 0x1 Interrupt not generated. 0x1 Interrupt not generated.
GPIO5_RISE_MASK 0x1 Interrupt not generated. 0x1 Interrupt not generated.
GPIO6_RISE_MASK 0x1 Interrupt not generated. 0x1 Interrupt not generated.
GPIO7_RISE_MASK 0x1 Interrupt not generated. 0x1 Interrupt not generated.
GPIO8_RISE_MASK 0x1 Interrupt not generated. 0x1 Interrupt not generated.
MASK_GPIO9_11 /
MASK_GPIO9_10
GPIO9_FALL_MASK 0x1 Interrupt not generated. 0x1 Interrupt not generated.
GPIO9_RISE_MASK 0x1 Interrupt not generated. 0x1 Interrupt not generated.
GPIO10_FALL_MASK 0x1 Interrupt not generated. 0x1 Interrupt not generated.
GPIO11_FALL_MASK 0x1 Interrupt not generated. 0x1 Interrupt not generated.
GPIO10_RISE_MASK 0x1 Interrupt not generated. 0x1 Interrupt not generated.
GPIO11_RISE_MASK 0x1 Interrupt not generated. 0x1 Interrupt not generated.
MASK_STARTUP NPWRON_START_MA
SK
0x1 Interrupt not generated. 0x1 Interrupt not generated.
ENABLE_MASK 0x0 Interrupt generated 0x0 Interrupt generated
FSD_MASK 0x1 Interrupt not generated. 0x1 Interrupt not generated.
SOFT_REBOOT_MAS
K
0x0 Interrupt generated 0x0 Interrupt generated
MASK_MISC TWARN_MASK 0x0 Interrupt generated 0x0 Interrupt generated
BIST_PASS_MASK 0x0 Interrupt generated 0x0 Interrupt generated
EXT_CLK_MASK 0x1 Interrupt not generated. 0x1 Interrupt not generated.
MASK_MODERATE_E
RR
BIST_FAIL_MASK 0x0 Interrupt generated 0x0 Interrupt generated
REG_CRC_ERR_MAS
K
0x0 Interrupt generated 0x0 Interrupt generated
SPMI_ERR_MASK 0x0 Interrupt generated 0x0 Interrupt generated
NPWRON_LONG_MAS
K
0x1 Interrupt not generated. 0x1 Interrupt not generated.
NINT_READBACK_MA
SK
0x0 Interrupt generated 0x0 Interrupt generated
NRSTOUT_READBAC
K_ MASK
0x0 Interrupt generated 0x1 Interrupt not generated.
MASK_FSM_ERR IMM_SHUTDOWN_MA
SK
0x0 Interrupt generated 0x0 Interrupt generated
MCU_PWR_ERR_MAS
K
0x0 Interrupt generated 0x0 Interrupt generated
SOC_PWR_ERR_MAS
K
0x0 Interrupt generated 0x0 Interrupt generated
ORD_SHUTDOWN_MA
SK
0x0 Interrupt generated 0x0 Interrupt generated
Static NVM Settings www.ti.com
26 Optimized Dual TPS6594-Q1 PMIC User Guide for Jacinto
™
7 DRA829 or
TDA4VM Automotive PDN-0C
SLVUC99 – JANUARY 2022
Submit Document Feedback
Copyright © 2022 Texas Instruments Incorporated
