5.2 Device Identification Settings
These settings are used to distinguish which device is detected in a system. These settings cannot be changed
after device startup.
Table 5-2. Device Identification NVM Settings
Register Name Field Name
TPS65941213-Q1 TPS65941111-Q1
Value Description Value Description
DEV_REV DEVICE_ID 0x82 0x82
NVM_CODE_1 TI_NVM_ID 0x13 0x11
NVM_CODE_2 TI_NVM_REV 0x4 0x3
PHASE_CONFIG MP_CONFIG 0x3 3+1+1 0x0 4+1
5.3 BUCK Settings
These settings detail the voltages, configurations, and monitoring of the BUCK rails stored in the NVM. All these
settings can be changed though I
2
C after startup. Some settings, typically the enable bits, are also changed by
the PFSM, as described in Section 6.3.
After the Section 6.3.8 sequence has completed, the BUCKx_EN bit is set for BUCK1, BUCK4, and BUCK5 in
the TPS65941213. BUCKx_EN is set for the BUCK1 and BUCK5 in the TPS65941111. The BUCKx_VMON_EN
bit is set for BUCK1, BUCK3, BUCK4 and BUCK5 in the TPS65941213. The BUCKx_VMON_EN bit is set for
BUCK1 and BUCK5 in the TPS65941213. The BUCKx_RV_SEL bit is cleared for all BUCKs. The other bits
remain unchanged, but are still accessible via I
2
C.
Table 5-3. BUCK NVM Settings
Register Name Field Name
TPS65941213-Q1 TPS65941111-Q1
Value Description Value Description
BUCK1_CTRL BUCK1_EN 0x0 Disabled; BUCK1 regulator 0x0 Disabled; BUCK1 regulator
BUCK1_FPWM 0x0 PFM and PWM operation
(AUTO mode).
0x0 PFM and PWM operation
(AUTO mode).
BUCK1_FPWM_MP 0x0 Automatic phase adding and
shedding.
0x0 Automatic phase adding and
shedding.
BUCK1_VMON_EN 0x0 Disabled; OV, UV, SC and
ILIM comparators.
0x0 Disabled; OV, UV, SC and
ILIM comparators.
BUCK1_VSEL 0x0 BUCK1_VOUT_1 0x0 BUCK1_VOUT_1
BUCK1_PLDN 0x1 Enabled; Pull-down resistor 0x1 Enabled; Pull-down resistor
BUCK1_RV_SEL 0x1 Enabled 0x1 Enabled
BUCK1_CONF BUCK1_SLEW_RATE 0x3 5.0 mV/μs 0x3 5.0 mV/μs
BUCK1_ILIM 0x5 5.5 A 0x5 5.5 A
BUCK2_CTRL BUCK2_EN 0x0 Disabled; BUCK2 regulator 0x0 Disabled; BUCK2 regulator
BUCK2_FPWM 0x0 PFM and PWM operation
(AUTO mode).
0x0 PFM and PWM operation
(AUTO mode).
BUCK2_VMON_EN 0x0 Disabled; OV, UV, SC and
ILIM comparators.
0x0 Disabled; OV, UV, SC and
ILIM comparators.
BUCK2_VSEL 0x0 BUCK2_VOUT_1 0x0 BUCK2_VOUT_1
BUCK2_PLDN 0x1 Enabled; Pull-down resistor 0x1 Enabled; Pull-down resistor
BUCK2_RV_SEL 0x1 Enabled 0x1 Enabled
BUCK2_CONF BUCK2_SLEW_RATE 0x3 5.0 mV/μs 0x3 5.0 mV/μs
BUCK2_ILIM 0x5 5.5 A 0x5 5.5 A
www.ti.com Static NVM Settings
SLVUC99 – JANUARY 2022
Submit Document Feedback
Optimized Dual TPS6594-Q1 PMIC User Guide for Jacinto
7 DRA829 or
TDA4VM Automotive PDN-0C
17
Copyright © 2022 Texas Instruments Incorporated
