Texas Instruments LAUNCHXL-F28377S User Manual

www.ti.com LAUNCHXL-F28377S Hardware
7
SPRUI25D–June 2015–Revised March 2019
Submit Documentation Feedback
Copyright © 2015–2019, Texas Instruments Incorporated
LAUNCHXL-F28377S overview
Table 3. F28377S LaunchPad Pin Out and Pin Mux Options - J5, J7
Mux Value
J5 Pin J7 Pin
Mux Value
3 2 1 0 0 1 2 3
+3.3V 41 61 +5V
NC 42 62 GND
EM1RAS EM1A14 GPIO87 43 63 ADCIN15
EM1CAS EM1A13 GPIO86 44 64 ADCINA2
NC 45 65 ADCINA5
NC 46 66 ADCINB5
EM1D19 GPIO65 47 67 ADCINA3
NC 48 68 ADCINB3
EM1D15 GPIO69 49 69 ADCINA4
EM1D18 GPIO66 50 70 NC
Table 4. F28377S LaunchPad Pin Out and Pin Mux Options - J8, J6
Mux Value
J8 Pin J6 Pin
Mux Value
3 2 1 0 0 1 2 3
EPWM2A GPIO2 80 60 GND
EPWM2B GPIO3 79 59 GPIO91 EM1A18 EEM1DQM3
ADCSOCB0 CANRXB EPWM6A GPIO10 78 58 NC
OUTPUTXBAR7 SCIRXDB EPWM6B GPIO11 77 57 NC
CANRXA SCITXDB SPICLKA GPIO18 76 56 RESET#
CANTXA SCIRXDB SPISTEA GPIO19 75 55 GPIO63 SCITXDC EM1D21 EM2D5
NC 74 54 GPIO64 EM1D20 EM2D4
NC 73 53 GPIO99 EM2A1
DAC3 72 52 GPIO92 EM1A19 EM1BA1
DAC4 71 51 NC
