LAUNCHXL-F28377S overview
6.4 Bill of Materials (BOM)
Table 5 lists the LAUNCHXL-F28377S bill of materials.
Table 5. LAUNCHXL-F28377S Bill of Materials
Item Ref Varient Qty Description Mfg Part Number Vendor Stk Number
S3 All 1 SWITCH TACTILE SPST-NO 0.05A
24 V
Omron Electronics Inc-
EMC Div
B3F-3152 Digikey SW410-ND
S1 All 1 SWITCH TAPE SEAL 3 POS SMD
50 V
CTS
Electrocomponents
219-3MST Digikey CT2193MST-ND
F1 All 1 PTC RESETTABLE .50A 15 V 1812 Bourns Inc. MF-MSMF050-2 Digikey MF-MSMF050-2TR-ND
Q1 All 1 Crystal 10.0000MHz 30ppm 18 pF
60 Ω -40°C - 85°C Through Hole
HC49/US
CTS-Frequency
Controls
ATS100B-E Digikey CTX919-ND
Q3 All 1 CRYSTAL 12.0000 MHZ 18 pF
SMD
Abracon Corporation ABLS2-12.000MHZ-
D4Y-T
Digikey 535-9869-2-ND
JP1, JP2, JP4, JP5 All 4 CONN HEADER 2 POS 2.54 Wurth Electronics Inc 61300211121 Digikey 732-5315-ND
JP1, JP2, JP4, JP5 All 4 SHUNT JUMPER .1" BLACK GOLD 3M 969102-0000-DA Digikey 3M9580-ND
J12, J10 All 2 CONN HEADER 3 POS 2.54 Wurth Electronics Inc 61300311121 Digikey 732-5316-ND
QEP_A, QEP_B All 2 CONN HEADER 5 POS 2.54 Wurth Electronics Inc 61300511121 Digikey 732-5318-ND
J1, J2, J3, J4, J5, J6, J7,
J8
All 4 LaunchPad Headers Major League
Electronics
SSHQ-110-D-08-G-LF Major League
Electronics
SSHQ-110-D-08-G-LF
R16, R18, R19, R20, R21,
R25, R28, R30, R32
DNP 9 RES 0.0 Ω 1/4W 1206 SMD Panasonic - ECG ERJ-8GEY0R00V Digikey P0.0ETR-ND
CON1 All 1 CONN RECEPT MINI-USB TYPE B
SMT
Mill-Max
Manufacturing Corp.
897-43-005-00-100001 Digikey ED90341TR-ND
C50, C51, C52, C53, C54,
C55
All 6 CAP CER 1000 pF 50 V 10% X7R
0402
Murata Electronics
North America
GRM155R71H102KA0
1D
Digikey 490-1303-1-ND
C1, C5, C9, C12, C13,
C14, C16, C24, C26, C28,
C30, C31, C32, C33, C34,
C35, C36, C37, C39, C43,
C56, C57, C58, C59, C60,
C61, C62, C63, C64, C65,
C66, C67, C73, C74
All 34 CAP CER 0.1 µF 10 V 10% X5R
0402
Murata Electronics
North America
GRM155R61A104KA0
1D
Digikey 490-1318-1-ND
C68, C69, C70, C79, C81 All 5 CAP CER 10 µF 4 V 20% X6S
0603
Murata Electronics
North America
GRM188C80G106ME
47D
Digikey 490-10470-1-ND
C41, C44 All 2 CAP CER 10 µF 25 V Y5V 1210 Murata Electronics
North America
GRM32NF51E106ZA0
1L
Digikey 490-1893-1-ND
C2, C20, C21, C27, C29,
C42, C46, C47, C48, C49,
C71, C72, C75, C76, C77,
C78
All 16 CAP CER 2.2 µF 4 V 20% X5R
0402
Murata Electronics
North America
GRM155R60G225ME
15D
Digikey 490-4518-1-ND
